Wind Turbine Ventilation

“MAX AIR” is one of the leading manufacturer’s of Eco friendly and user friendly Industrial Wind Turbine Roof Ventilators. The turbine ventilator are specially designed and manufactured as per industrial specification and standards and rigorously tested to ensure to ensure durability and performance in extreme temperature and high wind conditions. The turbine ventilators are manufactured under stringent quality check at every stage of production and the material used for manufacturing turbine major components are tested, treated, formed and assembled as per the existing industrial specification and standards.

UNIQUE FEATURES OF WIND TURBINE :-

• Doesn’t require power of electricity
• Rigid Roll Formed Curved Vanes
• Weathered & Storm proof, strong corrosion resistance
• No Operating Cost, high air exhausting efficiency
• Economical and environmental friendly
• Teflon Pre sealed or UBC Bearing
• Light weight & with high revolving speed
• Virtually Maintenance Free

Different Model under our production capacity are as follows :-

Model: Mx6”, Mx8”, Mx 10”, Mx12”, Mx20”, Mx24”, Mx27”, Mx35”

Material Constitute

Available in material of SS/Aluminum
There are three kind of materials they are made of: (A) Stainless steel, (B) Vanes stainless steel+other galvanized sheet, (C) Vanes aluminum + other galvanized sheet.
Our Wind Turbine no power Air Ventilators are made of whole stainless steel, galvanized sheet and Aluminum which are anti-acid and anti-erosion and involve only one time investment fitted with UBC bearing imported and original USA make for longer life and durability.

Advantages:

1. It is no electricity or energy costing and noiseless, exhausting air naturally and effectively. It can work for a long time so as to make fresh air circulating.
2. Good surface self-lubricating performance, superior anti-corrosion, weather resistance, strong wear resistance, long service life, light weight and high sensitivity.
3. Minimum packing measurement & Easy to install.
4. Working condition: Temperature difference between indoor and outdoor is 0.45. It begins to revolve at the wind speed of 0.12m/s.
5.  Roof Angle: Applied in different roofing in the scope of 0-22.5 oblique angle.
6. Best Safety norms: Fastest removal of Harmful Gas from work shop reducing accidents and in case of fire out break our Max Air roof Turbine ventilators on the roof can make the smoke indoor flow out more quickly, at the same time which can bring out more time for the victims to escape and reduce the loss by the accident.
