Man Cooler
'Maxair' Mancoolers have been the perfect means of blowing a large volume of high velocity powerful air stream over a long distance with an effective cooling and comfort for workers to deliver peak performance. 'Maxair' Mancoolers are are robust in design with least maintenance requirement . Consists of specially designed Aerofoil impeller of cast aluminium alloy of high efficiency.
'Maxair' mancoolers are available in pedestal, Bracket and tubular models. pedestal model and Bracket model can be rotated on vertical axis as well as horizontal axis. If desired the angle or air stream can be adjusted in Tubular model of 'Maxair'' Mancoolers. Roller casters may be fitted to the Pedestal model.
'Maxair' Mancoolers are widely used in foundaries, furnances, steel folling mills, heat treatment plants. rubber processing plants for rubberdryin drying of perishable, edible commodities in cold storage and the plants where workers exposed to hot atmosphere.
Performance as per IS : 6272
Sweep |
Volt/ Phase |
Speed |
Power |
Total Air Delivery at |
Minimum Peak Air Delivery |
|||||
10 times |
15 times |
|||||||||
Inch |
mm |
Volts |
Phase |
R.P.M. |
(Watts) HP |
C.F.M. |
M/3hr. |
(M/Min) |
(M/Min) |
|
19 |
483 |
230 |
Single |
1440 |
375 |
0.5 |
7000 |
12000 |
200 |
120 |
